Energy Storage System Stackable -

10+ Years Life

Smart Battery (Can Be Parallel Up To 16 Modules) Bluetooth Enabled.
10 Types Of Protection With Inbuilt Smart BMS Like -Over/Under Charge / Discharge, Temperature Management,
Balancing ETC. Wall Mounted Modular Cabinet.
Fast Charging/Discharging. Smart Display For Monitoring Purpose
Compatible With Most Of The Inverter In Market (LFP/LEAD ACID)

ENERGY STORAGE SYSTEM - STACKABLE
S. No.	MODEL	NESS-5LV1	NESS-5LV2	NESS-5LV3	NESS-5LV4
1	Number of Modules	1	2	3	4
2	Energy Capacity	100Ah	100Ah	100Ah	100Ah
3	Energy Capacity	4.8kWh	9.6kWh	14.4kWh	19.2kWh
4	Size(L×W×H)	574x395x134mm	574x395x302mm	574x395x470mm	574x395x638mm
5	Weight	49kg	88kg	127kg	166kg
6	Standard Charge/Discharge Current	75A	75A	100A	100A
7	Battery Type	Lithium Iron Phosphate (LFP)
8	Nominal Voltage	48V	96V	144V	192V
9	Operating Voltage Range	40-54.7V
10	Protection Grade	IP65
11	Installation	Floor installation
12	Operation Temperature	-10°C~60°C
13	Cycle Life	6000 Cycles
14	Communication Port	CAN
15	Warranty: 5 Years / 10 Years	Yes/optional
16	BMS Monitoring Parameters	SOC, System voltage,current, cell voltage, cell temperature, PCBA temperature measurement

S. No.	MODEL	NESS-5LV5	NESS-5LV6	NESS-5LV7	NESS-5LV8
1	Number of Modules	5	6	7	8
2	Energy Capacity	100Ah	100Ah	100Ah	100Ah
3	Energy Capacity	24kWh	28.8kWh	33.6kWh	38.4kWh
4	Size(L×W×H)	574x395x806mm	574x395x974mm	574x395x1142mm	574x395x1310mm
5	Weight	205kg	244kg	283kg	322kg
6	Standard Charge/Discharge Current	100A	100A	100A	100A
7	Battery Type	Lithium Iron Phosphate (LFP)
8	Nominal Voltage	240V	288V	336V	384V
9	Operating Voltage Range	40-54.7V
10	Protection Grade	IP65
11	Installation	Floor installation
12	Operation Temperature	-10°C~60°C
13	Cycle Life	6000 Cycles
14	Communication Port	CAN
15	Warranty: 5 Years / 10 Years	Yes/optional
16	BMS Monitoring Parameters	SOC, System voltage,current, cell voltage, cell temperature, PCBA temperature measurement
